Native Resolution SVGA (800x600) -
Projection System DLP® by Texas Instruments
Brightness 2500 ANSI Lumens -
Lamp 200W, 4000hours (Economic mode)
Contrast Ratio 2000:1 -
Weight 2.5 kg (5.5 lbs)
Noise Level 31/26 dB (normal / economic mode) -
Resolution Support VGA(640 x 480) to SXGA(1280 x 1024) -
Dimensions 9.4 x 4.18 x 9.88 inch (239 x 106.3 x 251 mm)
Image Size 24" to 300" -
Throw Ratio 54"@2m (54"@6.6 feet)
Zoom Ratio Manual zoom: 1.10:1 -
Lens F=2.4 to 2.48, f=20.7 to 22.8 mm
Display Color Full 16.7 million color palette -
Aspect Ratio 4:3/16:9 screen selectable
Horizontal Frequency 31 ~ 82 KHz -
Vertical Scan Rate 48 ~ 85Hz
Projection Position Front/Rear, Table/Ceiling
Input Terminals PC -
Analog RGB: D-sub 15 pin x 1
A/V
Analog RGB: D-sub 15 pin x 1 -
S-Video: Mini Din 4 pin x 1
Composite Video: RCA x 1 -
Stereo mini jack x 1
Output Terminals PC -
D-sub (15 pin) X 1
Audio -
2 Watt speaker x 1
Control Terminals Serial Connector : RS232 8 pin MINI DIN
Video Compatibility NTSC/PAL/SECAM
Auto Switching Power Supply 100 to 240 V AC, 50 to 60 Hz
Power Consumption 285W (max) |
